General features
MorelessPart no. | 08 0351 000 001 |
Degree of protection | IP67 |
Temperature range | -40 °C/+85 °C |
Additional information | for male panel mount connector |
Weight (g) | 4.13 |
Customs tariff number | 85366990 |
Country of Origin | HU |
Material
MorelessContact body material | silver |
Material protective cap | CuZn |
Strap material | Nylon |
REACH SVHC |
CAS 7439-92-1 (Lead) |
SCIP number | 4217ec10-f211-460d-9f6e-2a1f4ceec94c |
Surface | DIN 50968 - Cu/Ni4 halbmatt |
Classifications
MorelesseCl@ss 11.1 | 27-44-02-08 |
ETIM 9.0 | EC002314 |
Security notices
- The user must take suitable safety precautions to ensure that the connector cannot be accidentally disconnected.
